Description
The Baja Designs Squadron 2.0 Pro Flush Mount takes one of the most proven compact LED lights in off-road lighting and pushes it to the next level. Redesigned from the inside out, the Squadron 2.0 Pro combines increased output, next-generation optics, selectable backlighting, and an updated housing in a compact flush-mount package.
Producing an impressive 5,921 lumens at 65 watts, the Squadron 2.0 Pro delivers a 41% increase in performance over the previous generation. Redesigned optics improve beam control and put more usable light downrange, projecting farther and wider while reducing unwanted spill.
Whether you're lighting up technical trails, running across the open desert, or adding dependable auxiliary lighting to your adventure vehicle, the Squadron 2.0 Pro delivers outstanding nighttime visibility without requiring a large light housing.
Redesigned for More Performance
The new black aluminum flush-mount housing provides a clean, integrated installation that's ideal for bumpers, rear panels, bed racks, canopies, and other applications where a low-profile mounting solution is preferred.
Baja Designs has also updated the internal optics and lens patterns to produce a more refined and efficient beam. The improved uService® design incorporates secure clip-in reflectors for easier lens changes along with a redesigned gasket for improved sealing and long-term protection against dust, water, and harsh environments.
A new mounting system provides increased vertical adjustment, allowing you to precisely aim the light for your specific application.
Nine-Color Selectable Backlight
The Squadron 2.0 Pro now features an integrated color-selectable backlight with nine available colors, giving you the ability to customize the appearance of your lighting system to complement your vehicle or build.
A rugged 4-pin Deutsch connector supports the updated lighting functions while providing the durability and weather resistance expected from Baja Designs equipment.
Squadron 2.0 Pro Specifications
- Lumens: 5,921
- Power: 65W
- Current Draw: 4.7A @ 13.8V
- Operating Voltage: 12–32V
- Weather Protection: IP69K Rated
- Housing: Black aluminum flush mount
- Backlight: 9 selectable colors
- Connector: 4-pin Deutsch
- Serviceable: Baja Designs uService® technology
ELS Performance
Spot – Clear
ELS™: 86° / 6.1 / 454 / 4930
Driving Combo – Clear
ELS™: 128° / 7.4 / 403 / 4955
Wide Cornering – Clear
ELS™: 132° / 7.6 / 159 / 4946
Work/Scene – Clear
ELS™: 148° / 8.0 / 64 / 4575
What's Included
- (1) Baja Designs Squadron 2.0 Pro Flush Mount LED Light
- Required mounting hardware
Built for Serious Off-Road Lighting
From trail rigs and prerunners to Jeeps, trucks, UTVs, and overland builds, the Squadron 2.0 Pro Flush Mount delivers serious output from a compact footprint. With improved optics, substantially increased performance, selectable backlighting, and Baja Designs' proven construction, it's an excellent choice when you want maximum usable light without adding a bulky auxiliary light.
Backed by Baja Designs' 30-Day Satisfaction Guarantee and Limited Lifetime Warranty.
